■ Relay type:electromagnetic

■ Contacts configuration: SPDT

■ Rated coil voltage: 230V AC

■ AC contacts rating @R (at resistance load):10 A / 250 VAC

■ DC contacts rating @R (at resistance load):10 A / 30 VDC

■ Contact current: max.20A

■ Switched voltage: max 220V DC, max 400V AC

■ Relay variant: miniature

■ Mounting: PCB, socket

■ Coil resistance: 28kΩ

■ Body dimensions: 29 x 12.4 x 25mm

■ Coil power consumption: 1.2VA

■ Operating temperature: -40...85°C

■ Relay series: 40.31

■ Contact material: AgNi

■ Terminal pitch: 3.5mm

■ Coil current: 5mA
